Roving Frame Bottom Rollers

FEATURES : Bottom Rollers

    • CNIP Premium Material Composition: Bottom Rollers Engineered using a precise combination of high carbon, silicon, sulfur, nickel, chromium, and copper. Features a range of surface finishes from smooth to textured, tailored to specific application requirements.
    • Fast & Easy Jointing System: CNIP Bottom Rollers require no additional tools for assembly, enabling rapid, hassle-free setup.
    • Excellent Dimensional Stability: Bottom Rollers Maintains absolute precise tolerances and dimensions under intense operational conditions, standard across all CNIP products.
    • Optimized for Textile Bearings: Bottom Rollers Specifically engineered by CNIP to integrate seamlessly with high-performance textile machinery bearings.
    • High-Speed Operations:Bottom Rollers CNIP bottom rollers are dynamically balanced and designed to operate flawlessly at peak production speeds.
    • Unique Fine-Textured Surfaces:Bottom Rollers Specialized CNIP surface profiles enhance fiber grip, performance, and running stability during operation.

APPLICATIONS

Engineered to fit any global brand of spinning machinery, the CNIP Fluted Bottom Roller range delivers the precise performance and rugged durability needed to maximize your production efficiency.

Flutted Botom Rollers

Rieter - Roving Frame Bottom Rollers

** Custom Engineering Bottom Rollers: All CNIP Fluted Bottom Roller sizes, lengths, and dimensions are fully manufactured as per the customer's specific machinery requirements and technical drawings.
SR. NO DESCRIPTION TYPE OF MACHINE DIAMETER SPINDLE GUAGE SPINDLE BEARING TYPE MOQ
CNIP-01 Rieter Roving Frame Bottom Rollers F-10 & F-11 28.5 , 30 120 4 UL-19 100
CNIP-02 Rieter Roving Frame Bottom Rollers F-15 28.5, 30 , 32 110-130 4 UL-19 100
CNIP-03 Rieter Roving Frame Bottom Rollers F-19 28.5, 30 , 32 110-220 4 UL-3224 100
CNIP-04 Rieter Roving Frame Bottom Rollers F-20 28.5, 30 , 32 110-252 4 UL 3224 100
CNIP-05 Rieter Roving Frame Bottom Rollers F-33 28.5, 30 , 32 110-130 4 UL 3224 100
CNIP-06 Rieter Roving Frame Bottom Rollers F-35 28.5, 30 , 32 110-168 4 UL-19 100
CNIP-07 Rieter Roving Frame Bottom Rollers F-37 28.5, 30 , 32 110-220 4 UL-19 100
CNIP-08 Rieter Roving Frame Bottom Rollers F-39 28.5, 30 , 32 110-220 4 UL-3224 100
CNIP-09 Rieter Roving Frame Bottom Rollers F-40 28.5, 30 , 32 110-252 4 UL-19 100

Zinser - Roving Frame Bottom Rollers

** Custom Engineering Bottom Rollers: All CNIP Fluted Bottom Roller sizes, lengths, and dimensions are fully manufactured as per the customer's specific machinery requirements and technical drawings.
SR. NO DESCRIPTION TYPE OF MACHINE DIAMETER SPINDLE GUAGE SPINDLE BEARING TYPE MOQ
CNIP-01 Zinser Roving Frame Bottom Rollers 5 M 28.5, 30, 32 208-240 4 UL-3224 OR UL-19 100
CNIP-02 Zinser Roving Frame Bottom Rollers 5 A 28.5, 30, 32 220-260 4 UL-3224 OR UL-19 100
CNIP-03 Zinser Roving Frame Bottom Rollers 51 M 28.5, 30, 32 220-260 4 UL-3224 OR UL-19 100
CNIP-04 Zinser Roving Frame Bottom Rollers 670 28.5, 30, 32 260 4 UL-3224 OR UL-19 100
CNIP-05 Zinser Roving Frame Bottom Rollers 668 28.5, 30, 32 220-260 4 UL-3224 OR UL-19 100
CNIP-06 Zinser Roving Frame Bottom Rollers 664 28.5, 30, 32 220 4 UL-3224 OR UL-19 50
CNIP-07 Zinser Roving Frame Bottom Rollers 660 28.5, 30, 32 220-260 4 UL-3224 OR UL-19 50
CNIP-08 Zinser Roving Frame Bottom Rollers 68 i 28.5, 30, 32 220-260 4 UL-3224 OR UL-19 50

LMW Roving Frame Bottom Rollers

** Custom Engineering Bottom Rollers: All CNIP Fluted Bottom Roller sizes, lengths, and dimensions are fully manufactured as per the customer's specific machinery requirements and technical drawings.
SR. NO DESCRIPTION TYPE OF MACHINE DIAMETER SPINDLE GUAGE SPINDLE BEARING TYPE MOQ
CNIP-01 LMW Roving Frame Bottom Rollers LF 1400 28.5, 30, 32 220-260 4 UL-3224 OR UL-19 100
CNIP-02 LMW Roving Frame Bottom Rollers LF 1660 28.5, 30, 32 220-260 4 UL-3224 OR UL-19 100
CNIP-03 LMW Roving Frame Bottom Rollers LF 4200 28.5, 30, 32 220-260 4 UL-3224 OR UL-19 100
CNIP-04 LMW Roving Frame Bottom Rollers LF 4280 25, 32 28, 30 4 UL-28 100

MARZOLI Roving Frame Bottom Rollers

** Custom Engineering Bottom Rollers: All CNIP Fluted Bottom Roller sizes, lengths, and dimensions are fully manufactured as per the customer's specific machinery requirements and technical drawings.
SR. NO DESCRIPTION TYPE OF MACHINE DIAMETER SPINDLE GUAGE SPINDLE BEARING TYPE MOQ
CNIP-01 MARZOLI Roving Frame Bottom Rollers FT 6E 32, 27 110 4 UL-28 100
CNIP-02 MARZOLI Roving Frame Bottom Rollers FT 7E 32, 27 130 4 UL-28 100
CNIP-03 MARZOLI Roving Frame Bottom Rollers FT 60 32, 27 110 4 UL-28 100
CNIP-04 MARZOLI Roving Frame Bottom Rollers FT 70 32, 27 130 4 UL-28 100
CNIP-05 MARZOLI Roving Frame Bottom Rollers FT 7 32, 27 130 4 UL-28 100
CNIP-06 MARZOLI Roving Frame Bottom Rollers FTM 320 32, 27 110-130 4 UL-28 100

TOYOTA Roving Frame Bottom Rollers

** Custom Engineering Bottom Rollers: All CNIP Fluted Bottom Roller sizes, lengths, and dimensions are fully manufactured as per the customer's specific machinery requirements and technical drawings.
SR. NO DESCRIPTION TYPE OF MACHINE DIAMETER SPINDLE GUAGE SPINDLE BEARING TYPE MOQ
CNIP-01 TOYOTA Roving Frame Bottom Rollers FL-200 28.5, 32 110-130 4 UL-3224 OR UL-19 100
CNIP-02 TOYOTA Roving Frame Bottom Rollers FL-100 28.5, 32 110-120-130 4 UL-3224 OR UL-19 100
CNIP-01 TOYOTA Roving Frame Bottom Rollers FL-16 28.5, 32 110-130 4 UL-3224 OR UL-19 100
CNIP-04 TOYOTA Roving Frame Bottom Rollers FL-14 28.5, 32 110-130 4 UL-3224 OR UL-19 100
CNIP-06 TOYOTA Roving Frame Bottom Rollers FL-12 28.5, 32 110-130 4 UL-3224 OR UL-19 100
CNIP-04 TOYOTA Roving Frame Bottom Rollers FL-6 28.5, 32 110-130 4 UL-3224 OR UL-19 100
